Product Details:
|
| Product: | IP65 IP66 PC Display Monitors Computer | Touch Type: | 5 Wire Resisitive Touch Screen |
|---|---|---|---|
| Resolution: | 1024*768 | Brightness: | 350 Nits |
| CPU: | J1900 | RAM Optiaonal: | 2- 8GB |
| Storage: | 32- 512GB | Interface: | VGA/H-DMI /USB /COM / RJ45 |
| High Light: | Industrial Touch Screen Display 350 Nits,SUS304 Industrial Touch Screen Display,SUS304 industrial touch display |
||
15'' Industrial Resistive TouchScreen IP65 IP66 Waterproof PC Display Monitors Computer
The industrial waterproof panel WPPC series is a hign performance, high stability panel PC for food processing plants like dairy food and beverage plant, pharmaceutical industrial application, and other damp and harsh application environment. WPPC series offer all-in-one Capacitive (PCAP) or resistive touchscreen PC with 5 side water proof and protection grade IP65/66 as well as wide power range and wide operating temperature 0-60℃
Features:
Specifications:
| System | |
| CPU | Cele ron J1900 2.0-2.42G CPU |
| Chipset | In tel SOC |
| System Memory | 1-Ch DDR3L, 1333MHz SODIMM MAX 8GB |
| BIOS | AMI UEFI BIOS |
| Storage | 1*Simple-swap 2.5” SATA bay;1*mSATA(full size), support AHCI |
| Display | 15'' LCD |
| Touch | resistive touch |
| Expansion | 1*Mini PCIe(full size) with PCIe X1+USB,with SIM slot 1*Full size mSATA with USB2.0 |
| Real I/O |
2*RJ45 GbE LAN(with LED); 2* RS232/422/485(DB9) 1*USB3.0 Type A; 3*USB2.0 Type A 1*HD MI; 1*VGA; 1*Opt. ANT |
| LAN | 2*In tel I211AT PCIe Gig. Ethernet, 10/100/1000Mbps |
| Audio | Realtek ALC662VD controller, Support 5.1 channel |
| Control SW | 1*Power button, 1*AT/ATX Select dip |
| Power Supply | DC 9~36V, D-Jack w/ M8 connector, Comsuption: TDP 12V/ 1.62A |
| OS Supply | Wins 7, Wins 8.1, Wins 10, Linux Fedora Ubuntu |
|
Mechanical and Environmental |
|
| Construction |
he whole body: SUS304 Stainless steel Back cover: 3.0mm 5052 Aluminum IO cover: 1.0mm SECC/SGCC |
| Operating Temperature | 0~60℃ |
| Storage Temperature | -40°C~85°C |
| Operating Humidity | 10~90%@40℃, non-condensing |
| Shock | 10g peak acceleration(duration 11ms) |
| Vibration | 1g 5~500Hz |
| Mounting | Desktop VESA(100mm*100mm) mounting |
| Dimension | (W*H*D):405.22mm*328.22mm*52.1mm |
| Net Weight | 5.8KG |
| EMC | CE, FCC Class B |
| LCD | |
| Type | 15'' 'TFT LCD |
| Resolution | 1024*768 |
| Color | 16.2M colors |
| Pixel Pitch(mm) | 0.297*0.297 |
| Brightness(cd/m2) | 350 |
| Viewing Angle | 80 Degree(left), 80 Degree(right), 80 Degree(up), 80 Degree(down) |
| Operating Temperature | -20~70℃ |
| Backlight Lifetime | 50000 Hours |
| Touch | |
| Type | 5 wire resistive touch |
| Resolution | gapless |
| Light Transmittance | 83% |
| Interface | USB |
| Consumption | +5V @ 200mA |
| OS | Wins or Linux |
| Click Lifetime | 15 million times |
